K40H1203|IKW40N120H3 特点：
•最高结温度为175℃
•最高结温度为175℃
•非常低VCEsat
•低开关损耗
•较高的开关坚韧性
•低开关损耗
•较高的开关坚韧性
•内置快速恢复反并联二极管
•根据JEDEC1合格为目标
•无铅引脚电镀符合RoHS标准
•根据JEDEC1合格为目标
•无铅引脚电镀符合RoHS标准
•太阳能发电用逆变器
英飞凌K40H1203|IKW40N120H3 完美替代K40T120 (IKW40T120)|K40T1202 (IKW40N120T2) IGBT单管
英飞凌K40H1203|IKW40N120H3是英飞凌第三代1200V高开关速度IGBT单管, 能够完美替代K40T120|K40T1202 ，专用于焊接、太阳能发电逆变器和UPS等IGBT高频应用领域。
K40H1203( IKW40N120H3)|K40T120 (IKW405T120)|K40T1202 (IKW40N120T2) 参数比较说明：
|
Type |
VCE |
IC |
VCE(sat)
Tvj=
5°C |
Tvj
(max) |
Marking |
Package |
|
IKW40N120H3 |
1200V |
40A |
2.05V |
175°C |
K40H1203 |
PG-TO247-3 |
|
IKW40N120T2 |
1200V |
40A |
1.75V |
175°C |
K40T1202 |
PG-TO247-3 |
|
IKW40T120 |
1200V |
40A |
1.7V |
150°C |
K40T120 |
PG-TO247-3 |
K40H1203( IKW40N120H3)|K40T120 (IKW40T120)|K40T1202 (IKW40N120T2) 最大额定值比较说明:
|
Parameter |
Symbol |
Value |
Unit | ||
|
K40H1203 |
K40T1202 |
K40T120 | |||
|
Collector-emitter voltage |
VCE |
1200 |
1200 |
1200 |
V |
|
DC collector current
TC = 25°C
TC = 100°C |
IC |
80
40 |
752
40 |
75
40 |
A |
|
Pulsed collector current, tp limited by Tjmax |
ICpul s |
160 |
160 |
105 | |
|
Turn off safe operating area
VCE ≤ 1200V, Tj ≤ 150°C |
- |
160 |
160 |
105 | |
|
Diode forward current
TC = 25°C
TC = 100°C |
IF |
40
20 |
752
40 |
80
40 | |
|
Diode pulsed current, tp limited by Tjmax |
IFpul s |
160 |
160 |
105 | |
|
Gate-emitter voltage |
VGE |
±20 |
±20 |
±20 |
V |
|
Short circuit withstand time2)
VGE = 15V, VCC ≤ 1200V, Tj ≤ 150°C |
tSC |
10 |
10 |
10 |
us |
|
Power dissipation
TC = 25°C |
Pt ot |
483.0
220.0 |
480 |
270 |
W |
|
Operating junction temperature |
Tj |
-40...+175 |
-40...+175 |
-40...+150 |
°C |
|
Storage temperature |
Tstg |
-55...+150 |
-55...+150 |
-55...+150 | |
|
Soldering temperature, 1.6mm (0.063 in.) from case for 10s
Wavesoldering only, temperature on leads only |
- |
260 |
260 |
260 | |
|
Mounting torque,M3 screw
Maxim of mounting processes:3 |
M |
0.6 |
- |
- |
Nm |
